Grampian Classic 31
Designed by naval architect Peter van Dyne, of Annapolis.
Photos
Specifications on sailboatdata.com
Figures are transcribed from the sailboatdata.com record linked below and may differ from the owners’ figures elsewhere on this page. Metric values are theirs.
| Hull type | Fin keel | Rig | Cutter |
|---|---|---|---|
| L.O.A. | 30.92 ft / 9.42 m | L.W.L. | 22.29 ft / 6.79 m |
| Beam | 8.40 ft / 2.56 m | Draft | 4.40 ft / 1.34 m |
| Displacement | 9,722 lb / 4,410 kg | Sail area (reported) | 440 ft² / 40.88 m² |
| Construction | Fibreglass | First built | 1964 |
| Builder | Grampian Marine Ltd. (Canada) | Designer | Peter Van Dine |
| Engine (original) | Universal Atomic 4 (gas) |
Rig and sail particulars
| I | 33.50 ft / 10.21 m | J | 13.50 ft / 4.11 m |
|---|---|---|---|
| P | 29.50 ft / 8.99 m | E | 14.50 ft / 4.42 m |
| S.A. fore | 226.13 ft² / 21.01 m² | S.A. main | 213.88 ft² / 19.87 m² |
| S.A. total (100% fore + main) | 440.01 ft² / 40.88 m² | S.A. / Displ. (from rig) | 15.51 |
| Est. forestay length | 36.12 ft / 11.01 m |
Calculated ratios
| S.A. / Displ. | 15.51 | Displ. / Length | 391.90 |
|---|---|---|---|
| Comfort ratio | 35.46 | Capsize screening | 1.58 |
| S# | 1.09 | Hull speed | 6.33 kn |
| Pounds / inch immersion | 669.01 |
Source: Grampian Classic 31 — sailboatdata.com. Ratio definitions are on sailboatdata.
Jibs and genoas
Headsails are named by how far they overlap the mast: the LP (from the clew straight to the luff) as a percentage of J, the base of the foretriangle from the mast to the forestay.
Usual headsail sizes for this rig
| Name | LP % | LP | Area |
|---|---|---|---|
| #1 genoa | 150–155% | 20′ 3″ – 20′ 11″ | about 347–359 ft² |
| #2 genoa | 130–135% | 17′ 7″ – 18′ 3″ | about 301–313 ft² |
| Lapper (110% jib) | 110% | 14′ 10″ | about 255 ft² |
| Working jib or #3 | 90–100% | 12′ 2″ – 13′ 6″ | about 208–232 ft² |
| Heavy-weather jib | — | — | up to 151 ft² |
| Storm jib | — | — | up to 56 ft², with a luff up to 23′ 6″ |
Worked out from I = 33.5′ and J = 13.5′: a forestay of about 36′ 1″, and a full-hoist luff of about 34′ 4″ (95% of the forestay; area ≈ ½ × luff × LP). The heavy-weather and storm jib limits are World Sailing’s offshore rules: 13.5% and 5% of I², and a storm jib’s luff no more than 65% of the forestay.
The Classic 31 is a cutter. A cutter usually flies a high-cut yankee on the forestay, with a staysail inside it, rather than a big overlapping genoa.
Boats vary, and a roller furler shortens the luff by a foot or so. Measure your own forestay before ordering a sail, and have the sailmaker check.
